How to Retrieve SQL Data Automatically Using Google Sheets Script

Stephanie Lehuger
Stephanie Lehuger
Feb 14, 2020 · 7 min read
book

Follow this step-by-step explanation to learn how to automatically retrieve data from your SQL database and import it into Google Sheets with a script that you can copy and paste right into Google Apps.

How to automatically import data from SQL to Google Sheets

Create a Google Sheets script to import a SQL table (here with MySQL)

If you want to connect your Google spreadsheet to MySQL, here I’ll share with you the code to read data from your SQL database (here with MySQL) and import the whole table in Google Sheets.


1. Create a new Google Sheets by typing sheet.new in your browser toolbar

Create a new Google Sheets by typing sheet.new in your browser toolbar

2. Name your spreadsheet

Double click on the default name Untitled spreadsheet on the top left hand corner and replace it with the name you want. For instance, I chose to name it Test here.

Script to automatically retrieve SQL data, Name your spreadsheet
Script to automatically retrieve SQL data, Name your spreadsheet 2

3. Click on Tools > Script editor, this will open a new tab with a url starting with https://script.google.com/.

Script to automatically retrieve SQL data, editor
Script to automatically retrieve SQL data, Editor

4. Name your Google script

To name your script, click on the default name Untitled project on the top left hand corner. A little window will pop up where you can write the name you choose. For instance, I chose to name it like my spreadsheet: Test. Then, click on the OK button.

Script to automatically retrieve SQL data, Name your spreadsheet 3

5. Whitelist those addresses

Apps Script can connect to external databases through the JDBC service. It supports Google Cloud SQL, MySQL, Microsoft SQL Server, and Oracle databases. To update an external database with JDBC, your script must open a connection to the database and then make changes by sending SQL statements. In order to create a database connection using the JDBC service you must whitelist certain IP ranges in your database settings to allow Apps Script to access it. These are the address ranges you'll need to whitelist:

  • ‍64.18.0.0 - 64.18.15.255
  • 64.233.160.0 - 64.233.191.255
  • 66.102.0.0 - 66.102.15.255
  • 66.249.80.0 - 66.249.95.255
  • 72.14.192.0 - 72.14.255.255
  • 74.125.0.0 - 74.125.255.255
  • 173.194.0.0 - 173.194.255.255
  • 207.126.144.0 - 207.126.159.255
  • 209.85.128.0 - 209.85.255.255
  • 216.239.32.0 - 216.239.63.255
Script to automatically retrieve SQL data, Whitelist

6. In the code area, you’ll see some code already written:

Script to automatically retrieve SQL data, Code area

7. Delete this code:

Script to automatically retrieve SQL data, delete this code

Want a simpler, no-coding-required solution? Try Actiondesk for free!

8. Copy and paste the code below in the code area:


var server = '11.11.11.11';
var port = 3306;
var dbName = 'dummy';
var username = 'username';
var password = 'password';
var url = 'jdbc:mysql://'+server+':'+port+'/'+dbName;

function readData() {
 var conn = Jdbc.getConnection(url, username, password);
 var stmt = conn.createStatement();
 var results = stmt.executeQuery('SELECT * FROM dashboard_dummy');
 var metaData=results.getMetaData();
 var numCols = metaData.getColumnCount();
 var spreadsheet = SpreadsheetApp.getActive();
 var sheet = spreadsheet.getSheetByName('Sheet1');
 sheet.clearContents();
 var arr=[];

 for (var col = 0; col < numCols; col++) {
   arr.push(metaData.getColumnName(col + 1));
 }

 sheet.appendRow(arr);

while (results.next()) {
 arr=[];
 for (var col = 0; col < numCols; col++) {
   arr.push(results.getString(col + 1));
 }
 sheet.appendRow(arr);
}

results.close();
stmt.close();
sheet.autoResizeColumns(1, numCols+1);
}
Script to automatically retrieve SQL data, copy paste sceenshot


9. Replace the following information with your own in the code:



var server = '11.11.11.11'; // Replace 11.11.11.11 with your IP address
var port = 3306; // Replace 3306 with your port number. If you use a MySQL database, chances are that it’s the same, since port 3306 is the default port for the MySQL Protocol (port), which is used by the mysql client and MySQL Connectors.
var dbName = 'dummy'; // Replace dummy with your database name
var username = 'username'; // Replace username with your user name
var password = 'password'; // Replace password with your password
var results = stmt.executeQuery('SELECT * FROM dashboard_dummy'); // Replace dashboard_dummy with your table name
var sheet = spreadsheet.getSheetByName("Sheet1");// Replace Sheet1 with your Google Sheets tab name
Script to automatically retrieve SQL data, replace code

10. Click on the Run button (the arrow pointing to the bug on its right). Or, in the menu, on Run > Run function > readData.

Script to automatically retrieve SQL data, run

11. A little window will pop up entitled Authorization required. Click on the Review Permissions button.

Script to automatically retrieve SQL data, Review permissions

12. You might need to click in order to choose the Google account you are using to run your script. Click on the Allow button.

Script to automatically retrieve SQL data, Click allow

13. On top of your script, you’ll see a little message stating Running function readData. Be patient, as it might take a while to appear.

Script to automatically retrieve SQL data, Running Function readData

14. When the message disappears, go back to your sheet and… VOILA! You’ll have retrieved your SQL data in your spreadsheet :)

Script to automatically retrieve SQL data, results
excited. meme


Run a Google Sheets script automatically every minute to retrieve SQL data

Now I’ll show you the code to fetch and refresh your data every minute. Each time, it clears the existing content in the chosen sheet and replaces it with the database data while keeping the format you gave to the table in Google Sheets.


1. Just add this piece of code at the end of your current code:

ScriptApp.newTrigger('readData')
.timeBased()
.everyMinutes(1)
.create();

Script to automatically retrieve SQL data, add code to run every minute

2. Click on the Run button (the arrow pointing to the bug on its right). If a small window pops up titledAuthorization required, allow it again.

Script to automatically retrieve SQL data, run and authorize


That’s it! Now, you will import and automatically sync your data between your SQL database and Google Sheets. Yes, so simple and yet so powerful…

You got it. Meme



Conclusion


Using Google Sheets Script to retrieve SQL data is a relatively simple way to gain better visibility into your data, build powerful automated dashboards, improve reporting, and optimize your team's resource allocation and productivity. While a viable option, Google Sheets Script is not the most efficient or effective solution for importing and analyzing your SQL data. Actiondesk is that solution.


Actiondesk not only provides expanded capabilities and enables faster, simpler data imports and analysis; using the tool also requires no coding whatsoever. Designed to marry the functionality of an advanced BI tool with the simplicity of a spreadsheet, Actiondesk is a user-friendly spreadsheet solution. Import data from a wide variety of data sources, including HubSpot, Salesforce, MySQL, Intercom, and more, and rest assured that your data is always accurate and accessible in an intuitive spreadsheet. See it for yourself: try Actiondesk for free today.
